Sensors NMEA 2000 output
NMEA2000 output sensors with WiFi setup WEB interface
Showing all 13 results
$249.00Tank Level Pressure Sensor has range of 0 to 0.2 bars (0-3 psi) and it is atmospheric pressure compensated sensor. It will measure tanks with maximum depth about 200cm (78 inch) for water and about 250cm for fuel. The resolution is about 2mm (1/16 inch)
Tank Level Pressure Sensor
$249.00Add to cartQuick View
$229.00NMEA2000 Exhaust Gas Temperature (EGT) Sensor is suitable to measure high temperature range, including the engine exhaust gases temperature. NMEA2000 sentences that support temperature output
NMEA2000 Exhaust Gas Temperature (EGT) Sensor
$229.00Add to cartQuick View
$229.00Measures from -14.5 PSI (-1 Bar) to 30 PSI (2 Bar) with NMEA2000 interface. Perfect to measure the drop in pressure or vacuum building on RACOR-type fuel filters due to clogged filter element.
Once connected to the NMEA2000 network, the value can be displayed on any NMEA2000 MFD (Multi Function Display), or connected to our Vessel Monitoring and Smart Alarm System for early warning, before your engine starves for fuel and shuts down. Get one, do not get stranded!
Pressure Sensor for Single RACOR filter KIT -14.5 PSI to 30 PSI for single RACOR filter KIT
$229.00Add to cartQuick View
$189.00 – $219.00Pressure Sensor -14.5 psi to 30 psi (-1 bar to 2 bar) with NMEA2000 interface. Perfect to measure the drop of a pressure or vacuum building on RACOR-type fuel filters due to clogged filter element. Measure your engine turbo boost or fuel pressure to make sure the they are in the proper operating range.
Once connected to the NMEA2000 network, the value can be displayed on any NMEA2000 MFD (Multi Function Display), or connected to our Vessel Monitoring and Smart Alarm System for early warning, before your engine starves for fuel and shuts down. Get one, do not get stranded!
Pressure Sensor -14.5 psi to 30 psi
$189.00 – $219.00Select options This product has multiple variants. The options may be chosen on the product pageQuick View
$189.00CS-0-200-N2K
- Operating Voltage from 9V to 32V DC powered via NMEA 2000® port
- Power Consumption < 50mA / 100* mA
- NMEA 2000® LEN – 2 LEN
- Reverse polarity protection – Yes
- IP Rating IP66 NMEA2000® Box / IP64 Current Sensor
The setup is done via Wi-Fi interface on smartphone or computer web browser.
PGNs supported :
PGN59392 ISO Acknowledgement
PGN59904 ISO Request
PGN60160 Multi packet data transfer, TP.DT
PGN60416 Multi packet connection management
PGN60928 ISO Address Claim
PGN65240 Commanded Address
PGN126208 NMEA Request/Command/Acknowledge group function
PGN126464 PGN List (Transmit and Receive)
PGN126993 Heartbeat
PGN126996 Product information
PGN126998 Configuration informationCurrent Sensor -200A to 200A for DC
$189.00Add to cartQuick View- $189.00
CS-0-100-N2K
- Operating Voltage from 9V to 32V DC powered via NMEA 2000® port
- Power Consumption < 50mA / 100* mA
- NMEA 2000® LEN – 2 LEN
- Reverse polarity protection – Yes
- IP Rating IP66 NMEA2000® Box / IP64 Current Sensor
The setup is done via Wi-Fi interface on smartphone or computer web browser.
PGNs supported :
PGN59392 ISO Acknowledgement
PGN59904 ISO Request
PGN60160 Multi packet data transfer, TP.DT
PGN60416 Multi packet connection management
PGN60928 ISO Address Claim
PGN65240 Commanded Address
PGN126208 NMEA Request/Command/Acknowledge group function
PGN126464 PGN List (Transmit and Receive)
PGN126993 Heartbeat
PGN126996 Product information
PGN126998 Configuration informationCurrent Sensor -100A to 100A for DC
$189.00Add to cartQuick View - $189.00
CS-0-50-N2K
- Operating Voltage from 9V to 32V DC powered via NMEA 2000® port
- Power Consumption < 50mA / 100* mA
- NMEA 2000® LEN – 2 LEN
- Reverse polarity protection – Yes
- IP Rating IP66 NMEA2000® Box / IP64 Current Sensor
The setup is done via Wi-Fi interface on smartphone or computer web browser.
PGNs supported :
PGN59392 ISO Acknowledgement
PGN59904 ISO Request
PGN60160 Multi packet data transfer, TP.DT
PGN60416 Multi packet connection management
PGN60928 ISO Address Claim
PGN65240 Commanded Address
PGN126208 NMEA Request/Command/Acknowledge group function
PGN126464 PGN List (Transmit and Receive)
PGN126993 Heartbeat
PGN126996 Product information
PGN126998 Configuration informationCurrent Sensor -50A to 50A for DC
$189.00Add to cartQuick View - $189.00
CS-0-20-N2K
- Operating Voltage from 9V to 32V DC powered via NMEA 2000® port
- Power Consumption < 50mA / 100* mA
- NMEA 2000® LEN – 2 LEN
- Reverse polarity protection – Yes
- IP Rating IP66 NMEA2000® Box / IP64 Current Sensor
The setup is done via Wi-Fi interface on smartphone or computer web browser.
PGNs supported :
PGN59392 ISO Acknowledgement
PGN59904 ISO Request
PGN60160 Multi packet data transfer, TP.DT
PGN60416 Multi packet connection management
PGN60928 ISO Address Claim
PGN65240 Commanded Address
PGN126208 NMEA Request/Command/Acknowledge group function
PGN126464 PGN List (Transmit and Receive)
PGN126993 Heartbeat
PGN126996 Product information
PGN126998 Configuration informationCurrent Sensor -20A to 20A for DC
$189.00Add to cartQuick View - $189.00
CS-0-10-N2K
- Operating Voltage from 9V to 32V DC powered via NMEA 2000® port
- Power Consumption < 50mA / 100* mA
- NMEA 2000® LEN – 2 LEN
- Reverse polarity protection – Yes
- IP Rating IP66 NMEA2000® Box / IP64 Current Sensor
The setup is done via Wi-Fi interface on smartphone or computer web browser.
PGNs supported :
PGN59392 ISO Acknowledgement
PGN59904 ISO Request
PGN60160 Multi packet data transfer, TP.DT
PGN60416 Multi packet connection management
PGN60928 ISO Address Claim
PGN65240 Commanded Address
PGN126208 NMEA Request/Command/Acknowledge group function
PGN126464 PGN List (Transmit and Receive)
PGN126993 Heartbeat
PGN126996 Product information
PGN126998 Configuration informationCurrent Sensor -10A to 10A for DC
$189.00Add to cartQuick View
$189.00Measures from 0 to 200 PSI (14 Bar) output to NMEA2000 interface. Supports standard NMEA2000 pressure PGN130314.
Once connected to the NMEA2000 network, the value can be displayed on any NMEA2000 MFD (Multi Function Display), or connected to our Vessel Monitoring and Smart Alarm System for early warning and/or alarming.
Pressure Sensor 0 to 200 PSI
$189.00Add to cartQuick View- $189.00
Measures from 0 to 100 PSI (7 Bar) output to NMEA2000 interface. Supports standard NMEA2000 pressure PGN130314.
Once connected to the NMEA2000 network, the value can be displayed on any NMEA2000 MFD (Multi Function Display), or connected to our Vessel Monitoring and Smart Alarm System for early warning and/or alarming.
Pressure Sensor 0 to 100 PSI
$189.00Add to cartQuick View -
NMEA2000 Standard Temperature Sensor – SS Cylinder Terminal
$149.00Add to cartQuick View -
NMEA2000 Standard Temperature Sensor – Ring Terminal
$149.00Add to cartQuick View
